Hooking Candiru
Another Mercenary Spyware Ven
dor Comes into Focus
Summary
- Candiru is a secretive Israel-based company that sells spyware exclusively to governments. Reportedly, their spyware can infect and monitor iPhones, Androids, Macs, PCs, and cloud accounts.
- Using Internet scanning we identified more than 750 websites linked to Candiru’s spyware infrastructure. We found many domains masquerading as advocacy organizations such as Amnesty International, the Black Lives Matter movement, as well as media companies, and other civil-society themed entities.
- We identified a politically active victim in Western Europe and recovered a copy of Candiru’s Windows spyware.
- Working with Microsoft Threat Intelligence Center (MSTIC) we analyzed the spyware, resulting in the discovery of CVE-2021-31979 and CVE-2021-33771 by Microsoft, two privilege escalation vulnerabilities exploited by Candiru. Microsoft patched both vulnerabilities on July 13th, 2021.
- As part of their investigation, Microsoft observed at least 100 victims in Palestine, Israel, Iran, Lebanon, Yemen, Spain, United Kingdom, Turkey, Armenia, and Singapore. Victims include human rights defenders, dissidents, journalists, activists, and politicians.
- We provide a brief technical overview of the Candiru spyware’s persistence mechanism and some details about the spyware’s functionality.
- Candiru has made efforts to obscure its ownership structure, staffing, and investment partners. Nevertheless, we have been able to shed some light on those areas in this report.
1. Who is Candiru?
The company known as “Candiru,” based in Tel Aviv, Israel, is a mercenary spyware firm that markets “untraceable” spyware to government customers. Their product offering includes solutions for spying on computers, mobile devices, and cloud accounts.
Figure 1: A distinctive mural of five men with empty heads wearing suits and bowler hats is displayed in this “Happy Hour” photo a previous Candiru office posted on Facebook by a catering company.
A Deliberately Opaque Corporate structure
Candiru makes efforts to keep its operations, infrastructure, and staff identities opaque to public scrutiny. Candiru Ltd. was founded in 2014 and has undergone several name changes
(
see: Table 1). Like many mercenary spyware corporations, the company
reportedly recruits from the ranks of Unit 8200, the signals intelligence unit of the Israeli Defence Forces.
While the company’s current name is Saito Tech Ltd, we will refer to them as “Candiru” as they are most well known by that name. The firm’s corporate logo appears to be a silhouette of the reputedly-gruesome
Candiru fish in the shape of the letter “C.”
Candiru has at least one subsidiary: Sokoto Ltd.
Section 5 provides further documentation of Candiru’s corporate structure and ownership.
Reported Sales and Investments
According to a
lawsuit brought by a former employee, Candiru had sales of “nearly $30 million,” within two years of its founding. The firm’s reported clients are located in “Europe, the former Soviet Union, the Persian Gulf, Asia and Latin America.” Additionally, reports of possible deals with several countries have been published:
- Uzbekistan: In a 2019 presentation at the Virus Bulletin security conference, a Kaspersky Lab researcher stated that Candiru likely sold its spyware to Uzbekistan’s National Security Service.
- Saudi Arabia & the UAE: The same presentation also mentioned Saudi Arabia and the UAE as likely Candiru customers.
- Singapore: A 2019 Intelligence Online report mentions that Candiru was active in soliciting business from Singapore’s intelligence services.
- Qatar: A 2020 Intelligence Online report notes that Candiru “has become closer to Qatar.” A company linked to Qatar’s sovereign wealth fund has invested in Candiru. No information on Qatar-based customers has yet emerged,
Candiru’s Spyware Offerings
A leaked Candiru project proposal
published by TheMarker shows that Candiru’s spyware can be installed using a number of different vectors, including malicious links,
man-in-the-middle attacks, and physical attacks. A vector named “
Sherlock” is also offered, that they claim works on Windows, iOS, and Android. This may be a browser-based zero-click vector.
Like many of its peers, Candiru appears to license its spyware by
number of concurrent infections, which reflects the number of targets that can be under active surveillance at any one instant in time. Like NSO Group, Candiru also appears to restrict the customer to a set of approved countries.
The €16 million project proposal allows for an unlimited number of spyware infection attempts, but the monitoring of only 10 devices simultaneously. For an additional €1.5M, the customer can purchase the ability to monitor 15 additional devices simultaneously, and to infect devices in a single additional country. For an additional €5.5M, the customer can monitor 25 additional devices simultaneously, and conduct espionage in five more countries.
The fine print in the proposal states that the product will operate in “all agreed upon territories, ”then mentions a list of restricted countries including the US, Russia, China, Israel and Iran. This
same list of restricted countries has previously been mentioned by NSO Group. Nevertheless, Microsoft observed Candiru victims in
Iran, suggesting that in some situations, products from Candiru do operate in restricted territories. In addition, targeting infrastructure disclosed in this report includes domains masquerading as the Russian postal service.
The proposal states that the spyware can exfiltrate private data from a number of apps and accounts including Gmail, Skype, Telegram, and Facebook. The spyware can also capture browsing history and passwords, turn on the target’s webcam and microphone, and take pictures of the screen. Capturing data from additional apps, such as
Signal Private Messenger, is sold as an add-on.
For a further additional €1.5M fee, customers can purchase a
remote shell capability, which allows them full access to run any command or program on the target’s computer. This kind of capability is especially concerning, given that it could also be used to download files, such as planting incriminating materials,
onto an infected device.
2. Finding Candiru’s Malware In The Wild
Using telemetry data from Team Cymru, along with assistance from civil society partners, the Citizen Lab was able to identify a computer that we suspected contained a persistent Candiru infection. We contacted the owner of the computer, a politically active individual in Western Europe, and arranged for the computer’s hard drive to be imaged. We ultimately extracted a copy of Candiru’s spyware from the disk image.
While analysis of the extracted spyware is ongoing, this section outlines initial findings about the spyware’s persistence
Persistence
Candiru’s spyware was persistently installed on the computer via COM hijacking of the following registry key:
HKEY_LOCAL_MACHINE\Software\Classes\CLSID\{CF4CC405-E2C5-4DDD-B3CE-5E7582D8C9FA}\InprocServer32
Normally, this registry key’s value points to the benign
Windows Management Instrumentation wmiutils.dll file, but the value on the infected computer had been modified to point to a malicious DLL file that had been dropped inside the Windows system folder associated with the Japanese input method (IMEJP) C:\WINDOWS\system32\ime\IMEJP\IMJPUEXP.DLL. This folder is benign and included in a default install of Windows 10, but IMJPUEXP.DLL is not the name of a legitimate Windows component.
When Windows boots, it automatically loads the Windows Management Instrumentation service, which involves looking up the DLL path in the registry key, and then invoking the DLL.
Loading the Spyware’s Configuration
The IMJPUEXP DLL file has eight blobs in the PE resources section with identifiers 102, 103, 105, 106, 107, 108, 109, 110. The DLL decrypts these using an AES key and IV that are hardcoded in the DLL. Decryption is via Windows CryptoAPI, using AES-256-CBC.
Of particular note is resource 102, which contains the path to the legitimate wmiutils.dll, which is loaded after the spyware, ensuring that the COM hijack does not disrupt normal Windows functionality. Resource 103 points to a file AgentService.dat in a folder created by the spyware, C:\WINDOWS\system32\config\spp\Licenses\curv\config\tracing\. Resource 105 points to a second file in the same directory, KBDMAORI.dat.
IMJPUEXP.DLL decrypts and loads the AgentService.dat file whose path is in resource 103, using the same AES key and IV, and decompresses it via zlib. AgentService.dat file then loads the file in resource 105, KBDMAORI.dat, using a second AES key and IV hardcoded in AgentService.dat, and performs the decryption using a statically linked OpenSSL. Decrypting KBDMAORI.DAT yields a file with a series of nine encrypted blobs, each prefixed with an 8-byte little-endian length field. Each blob is encrypted with the same AES key and IV used to decrypt KBDMAORI.DAT, and is then zlib compressed.
The first four encrypted blobs appear to be DLLs from the Microsoft Visual C++ redistributable: vcruntime140.dll, msvcp140.dll, ucrtbase.dll, concrt140.dll. The subsequent blobs are part of the spyware, including components that are apparently called Internals.dll and Help.dll. Both the Microsoft DLLs and the spyware DLLs in KBDMAORI.DAT are lightly obfuscated. Reverting the following modifications makes the files valid DLLs:
- The first two bytes of the file (MZ) have been zeroed.
- The first 4 bytes of NT header (\x50\x45\x00\x00) have been zeroed.
- The first 2 bytes of the optional header (\x0b\x02) have been zeroed.
- The strings in the import directory have been XOR obfuscated, using a 48-byte XOR key hardcoded in AgentService.dat:
6604F922F90B65F2B10CE372555C0A0C0C5258B6842A83C7DC2EE4E58B363349F496E6B6A587A88D0164B74DAB9E6B58
The final blob in KBDMAORI.DAT is the spyware’s configuration in JSON format. The configuration is somewhat obfuscated, but clearly contains Base64 UTF-16 encoded URLs for command-and-control.
All three domain names pointed to 185.181.8[.]155. This IP address was connected to three other IPs that matched our Candiru fingerprint
CF1 (Section 3).
Spyware Functionality
We are still reversing most of the spyware’s functionality, but Candiru’s Windows payload appears to include features for exfiltrating files, exporting all messages saved in the Windows version of the popular encrypted messaging app
Signal, and stealing cookies and passwords from Chrome, Internet Explorer, Firefox, Safari, and Opera browsers. The spyware also makes use of a legitimate signed third-party driver,
physmem.sys:
c299063e3eae8ddc15839767e83b9808fd43418dc5a1af7e4f44b97ba53fbd3d
Microsoft’s
analysis also established that the spyware could send messages from logged-in email and social media accounts directly on the victim’s computer. This could allow malicious links or other messages to be sent
directly from a compromised user’s computer. Proving that the compromised user did not send the message could be quite challenging.
3. Mapping Candiru’s Command & Control Infrastructure
To identify the websites used by Candiru’s spyware, we developed four fingerprints and a new Internet scanning technique. We searched historical data from
Censys and conducted our own scans in 2021. This led us to identify at least 764 domain names that we assess with moderate-high confidence to be used by Candiru and its customers. Examination of the domain names indicates a likely interest in targets in Asia, Europe, the Middle East, and North America.
Additionally, based on our analysis of Internet scanning data, we believe that there are Candiru systems operated from Saudi Arabia, Israel, UAE, Hungary, and Indonesia, among other countries.
OPSEC Mistake by Candiru Leads to their Infrastructure
Using Censys, we found a self-signed TLS
certificate that included the email address “
[email protected]”. We attributed the candirusecurity[.]com domain name to Candiru Ltd, because a second domain name (
verification[.]center) was registered in 2015 with a candirusecurity[.]com email address and a phone number (+972-54-2552428) listed by Dun & Bradstreet as the
fax number for Candiru Ltd, also known as Saito Tech Ltd.
Censys data records that a total of six IP addresses returned this certificate: 151.236.23[.]93, 69.28.67[.]162, 176.123.26[.]67, 52.8.109[.]170, 5.135.115[.]40, 185.56.89[.]66. The latter four of these IP addresses subsequently returned
another certificate, which we fingerprinted (
Fingerprint CF1) based on distinctive features. We searched Censys data for this fingerprint.
We found 42 certificates on Censys matching
CF1. We observed that six IPs matching
CF1 certificates later returned certificates that matched a second fingerprint we devised,
CF2. The
CF2 fingerprint is based on certificates that match those generated by a “Fake Name” generator. We first ran an SQL query on Censys data for the fingerprint, and then filtered by a list of fake names.
The SQL query yielded 572 results. We filtered the results, requiring the TLS certificate’s organization in the parsed.subject_dn field to contain an entry from the
list of 475 last names in the Perl Data-Faker module. We suspect that Candiru is using either this Perl module, or another module that uses the same word list, to generate fake names for TLS certificates. Neither the Perl Data-Faker module, nor other similar modules (e.g., the Ruby Faker Gem, or the PHP Faker module) appear to have built-in functionality for generating fake TLS certificates. Thus, we suspect that the TLS certificate generation code is custom code written by Candiru. After filtering, we found 542 matching certificates.
We then developed an HTTP fingerprint, called
BRIDGE, with which we scanned the Internet and built a third TLS fingerprint,
CF3. We are keeping the
BRIDGE and
CF3 fingerprints confidential for now in order to maintain visibility into Candiru’s infrastructure.
Overlap with CHAINSHOT
One of the IPs that matched our
CF1 fingerprint, 185.25.50[.]194, was pointed to by dl.nmcyclingexperience[.]com, which is mentioned as a final URL of a spyware payload delivered by the CHAINSHOT exploit kit in a
2018 report. CHAINSHOT is believed to be linked to Candiru, though no public reports have outlined the basis for this attribution, until now. Kaspersky has observed UAE hacking group
Stealth Falcon
using CHAINSHOT, as well as an Uzbekistan-based customer that they call
SandCat. While numerous analyses have focused on various CHAINSHOT exploitation techniques, we have not seen any public work that examines Candiru’s final Windows payload.
Overlap with Google TAG Research
On 14 July 2021, Google’s Threat Analysis Group (TAG)
published a report that mentions two Chrome zero-day exploits that TAG observed used against targets (
CVE-2021-21166 and
CVE-2021-30551). The report mentions nine websites that Google determined were used to distribute the exploits. Eight of these websites pointed to IP addresses that matched our
CF3 Candiru fingerprint. We thus believe that the attacks that Google observed involving these Chrome exploits were linked to Candiru.
Google also linked a further Microsoft Office exploit they observed (
CVE-2021-33742) to the same operator.
Targeting Themes
Examination of Candiru’s targeting infrastructure permits us to make guesses about the location of potential targets, and topics and themes that Candiru operators believed that targets would find relevant and enticing.
Some of the themes strongly suggest that the targeting likely concerned civil society and political activity. This troubling indicator matches with Microsoft’s observation of the extensive targeting of members of civil society, academics, and the media with Candiru’s spyware. We observed evidence of targeting infrastructure masquerading as media, advocacy organizations, international organizations, and others (s
ee: Table 4).
We found many aspects of this targeting concerning, such as the domain blacklivesmatters[.]info, which may be used to target individuals interested in or affiliated with this movement. Similarly, infrastructure masquerading as Amnesty International and Refugee International are troubling, as are lookalike domains for the United Nations, World Health Organization, and other international organizations. We also found the targeting theme of gender studies (e.g. womanstudies[.]co & genderconference[.]org) to be particularly interesting and warranting further investigation.
A range of targeting domains appears to be reasonably country-specific (s
ee: Table 5). We believe these domain themes indicate likely countries of
targets and not necessarily the countries of the operators themselves.
