Navy 3rd Mogami class FFG to be launched

Gary

Experienced member
Messages
8,201
Reactions
21 12,732
Nation of residence
Indonesia
Nation of origin
Indonesia

Mogami-class escort ship FFM-3, named and launched at Mitsubishi Nagasaki Shipyard & Machinery Works on June 22​

Posted: June 15, 2021

Image courtesy of Ministry of Defense
The Maritime Self-Defense Force announced that a naming and launching ceremony will be held on June 22, 2021 (Tuesday) for the Mogami-class Reiwa first year planned escort ship (01FFM) under construction at Mitsubishi Heavy Industries Nagasaki Shipyard & Machinery Works. did.
The third new escort ship, which is being built as a mogami-class escort ship, will be launched on June 22 (Tuesday). Construction of the ship was laid down in July 2020, and the launch of the same type of ship at Nagasaki Shipyard will be the second ship following the first ship "Mogami (FFM-1)".
The executor of the naming and launching ceremony is Mr. Yoshitsugu Deguchi, the Sasebo District Chief. The ceremony will be held from 9:52 to 10:05.



Saithan

Experienced member
Denmark Correspondent
Messages
8,292
Reactions
24 19,055
Nation of residence
Denmark
Nation of origin
Turkey
Japan’s MHI Launches ‘Noshiro’ 「のしろ」Third 30FFM Mogami-class Frigate For The JMSDF
Launch ceremony of “Noshiro”. JMSDF picture.

Japan’s MHI Launches ‘Noshiro’ 「のしろ」Third 30FFM Mogami-Class Frigate For The JMSDF​

Japanese shipbuilder Mitsubishi Heavy Industries (MHI) in Nagasaki launched today "Noshiro", the third Mogami-class vessel. Also known as 30FFM, it is a next generation frigate for the Japan Maritime Self-Defense Force (JMSDF).​

Xavier Vavasseur 22 Jun 2021

The first ship-in-class, Mogami, was launched in March 2021 by MHI (Naval News was on site to cover the event) while another shipyard, Mitsui E & S Shipbuilding located in Okayama launched the second ship of the class, Kumano, back in November 2020. This is because Mitsui E&S received a subcontracting order from MHI (the main contractor) for the construction of the 3,900-ton frigate for the JMSDF.

The vessel is named after the Noshiro River (のしろ, Noshiro-gawa) located in Akita Prefecture, Japan. According to the JMSDF “The Noshiro River has supported tens of thousands people since ancient times.” The shipyard will now proceed to the fitting out stage of the frigate, ahead of its delivery and commissioning set for 2022

30FFM (also known as FFM and previously known as 30DX) is the next generation multi-mission frigate designed for the Japan Maritime Self-Defense Force (JMSDF). A total number of 22 Frigates are expected to be procured for the JMSDF.

The two shipyards in charge of building the first two frigates of the class are Mitsubishi Heavy Industries (MHI) in Nagasaki and Mitsui E&S in Okayama.

30FFM characteristics​

Japan’s MHI Launches ‘Noshiro’ 「のしろ」Third 30FFM Mogami-class Frigate For The JMSDF
Launch ceremony of “Noshiro”, the third Mogami-class Frigate for the JMSDF at the MHI shipyard in Nagasaki. MHI picture.

According to MHI, the 30FFM multi-mission frigate will have a full load displacement of about 5,500 tons, with a length of 132.5 meters and a beam of 16.3 meters. It will have a maximum speed in excess of 30 knots. The crew complement will be quite low, at about 90 sailors, indicating a high level of automation on board.

The 30FFM will be equipped with a wide variety of weapons and systems as listed below.
  • BAE Systems Mk.45 mod.4 5-inch naval gun system ×1
  • Japan Steel Works 12.7mm Remote Weapon System ×2
  • Mk.41 VLS (fitted for but not with)
  • Raytheon SeaRAM ×1
  • MHI Type 17 anti-ship missiles ×8
  • Mitsubishi Electric OPY-2 multifunction Radar
  • Mitsubishi Electric OAX-3EO/IR sensors
  • Hitachi OQQ-11 anti-mine sonar
  • NEC OQQ-25 anti-submarine sonar (VDS/TASS)
  • UUV (OZZ-5 by MHI) and USV (unknown type) for mine counter measures
  • Sea mines for offensive mine warfare

You can learn more about the 30FFM class with the in-depth feature we published last year:



_____________________________________________

The power of solid economy and workforce ethics.


Saithan

Experienced member
Denmark Correspondent
Messages
8,292
Reactions
24 19,055
Nation of residence
Denmark
Nation of origin
Turkey

30FFM: Japan’s Next Generation Frigate Taking Shape At Two Shipyards​

Two Future Multi-Mission Frigates (FFM or 30FFM) are starting to take shape at two shipyards in Japan. Images and videos obtained by Naval News from local shipspotters show the integrated mast has been fitted. Both hulls should be ready for launch before the end of the year. Xavier Vavasseur and Yoshihiro Inaba report.​

Xavier Vavasseur 21 Sep 2020

Yoshihiro Inaba contributed to this story

30FFM (also known as FFM and previously known as 30DX) is the next generation multi-mission frigate designed for the Japan Maritime Self-Defense Force (JMSDF). A total number of 22 Frigates are expected to be procured for the JMSDF.

The two shipyards in charge of building the first two frigates of the class are Mitsubishi Heavy Industries (MHI) in Nagasaki and Mitsui E&S in Okayama.

The first 30FFM frigate at MHI berth #2 in Nagasaki:
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-3-1024x768.jpg
    15 August 2020
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-4-1024x768.jpg
    22 August 2020
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-2-1024x768.jpg
    14 August 2020
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-5-1024x768.jpg
    29 August 2020
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-6-1024x768.jpg
    29 Augsut 2020

The second 30FFM frigate at an advanced stage of construction at Mitsui E&S in Okayama:


The-second-30FFM-frigate-at-an-advanced-stage-of-construction-at-Mitsui-ES-in-Okayama-1024x683.jpg
Picture taken 22 August 2020 by @R1000_PILOT

While in early August, the hulls were still missing their integrated mast at both locations, recent pictures showed the mast and hangar in place on the hull at Mitsui E&S in mid-August. The mast on the hull at MHI was installed the last week of August.

30FFM characteristics​



According to MHI, the 30FFM multi-mission frigate will have a full load displacement of about 5,500 tons, with a length of 132.5 meters and a beam of 16.3 meters. It will have a maximum speed in excess of 30 knots. The crew complement will be quite low, at about 90 sailors, indicating a high level of automation on board.

Atsui Yoshioka, Senior Project Manager of the Next Generation Surface Ship Project at MHI previously told Naval News at Sea Air Space 2019 that the main requirements that drove the design of this future ship are:
  • Very low radar cross section
  • Very high speed
  • Reduced crew
  • Ability to launch and recover unmanned systems

To achieve such as high speed (over 30 knots), the frigate will be fitted with a CODAG propulsion system consisting in a single Rolls Royce MT-30 gaz turbine and two MAN 12V28/33D diesel engines. Early designs of the frigate showed a combination of waterjet and propellers but the newer scale model (unveiled at SAS 2018 and showcased at various trade shows ever since) doesn’t show the underside of the hull anymore.

30FFM Advanced Integrated CIC​

30FFM CIC
The CIC features the giant 360° wall and 14 + 4 multi function consoles + 2 large tactile tables.

As we reported during SAS 2019, the 30FFM will feature a very advanced and futuristic 360° video wall in its Combat Information Center (CIC). Named the “Advanced Integrated CIC” by MHI, the CIC of the 30FFM features a circular arrangement (while every other CICs are either in square or rectangle shape) and comprises:
  • An outer rim, with 14 multi function consoles (plus two extra seats), all facing the wall
  • 3 rows at the center of the circle arrangement consisting in:
  • (what looks like) a central helm station
  • 4 more multi-function consoles (likely for the commanding officer and his XO)
  • 2 large horizontal tactical table likely for cooperative mission planning and navigation purpose

According to MHI, the 360° giant screen fulfills many roles. It can be used to display the direct surroundings of the frigate, fusing the feed and data from the many electro optical, infra red, video and even radar sensors onboard. The augmented reality technology will greatly help the crew in the field of navigation, asymmetric warfare and even in the phase of launch and recovery of unmanned surface vehicles.

In addition, the “video wall” can display any kind of information typically displayed on multi-function consoles. We were shown that the information from the engine control room, and typically displayed as part of the integrated platform management system (IPMS) can now be displayed in the CIC thanks to the video wall. Tasks such as engine control, damage control, fire fighting control can now take place from inside the CIC.

30FFM Missions​

JMSDF-Future-Frigate-to-Feature-Futuristic-360%C2%B0-Augmented-Reality-Wall-10-1024x768.jpg
Artist impression: 30FFM evading the radar from a J-20 Mighty Dragon stealth fighter thanks to its reduced radar cross section features.

The 30 FFM will increase the current number of vessels in the JMSDF as well as replace older vessels that have been responsible for coastal defense and minesweeping. So it is designed for a very wide range of missions.

Patrol around Japan​

The main mission of the 30 FFM in peacetime will be to patrol the waters around Japan. Currently, this is a mission of older destroyer (Abukuma, Hatsuyuki and Asagiri class), but the 30FFM will take over this mission by replacing these vessels.

Island Defense​

As explained later, the 30FFM is equipped with Mk.45 mod.4 5-inch gun and is also given a minesweeping/mine-laying capability. Therefore, it can be inferred that the 30FFM is also useful for island defense.
The Mk.45 is ideal for attacking enemies that have landed on the island. Also, in order to land friendly troops, it is necessary to sweep the mines laid by the enemy.In addition, laying mines to deter enemy landings is also useful.

Overseas deployment​

Currently, JMSDF continues to send destroyers to work with countries around the world to deter piracy off the coast of Somalia, Africa. However, this activity has become a huge burden for JMSDF, especially because of the North Korean situation and the increased duties of the JMSDF in the wake of China’s maritime expansion. Therefore, it is intended to send the 30 FFM to these international contributions overseas and to dedicate the destroyer to missions against China and North Korea.

30FFM weapons, sensors and unmanned systems​

JMSDF-Future-Frigate-to-Feature-Futuristic-360%C2%B0-Augmented-Reality-Wall-12-1024x768.jpg
Sensor systems aboard the 30FFM

The 30FFM will be equipped with a wide variety of weapons and systems as listed below.
  • BAE Systems Mk.45 mod.4 5-inch naval gun system ×1
  • Japan Steel Works 12.7mm Remote Weapon System ×2
  • Mk.41 VLS (fitted for but not with)
  • Raytheon SeaRAM ×1
  • MHI Type 17 anti-ship missiles ×8
  • Mitsubishi Electric OPY-2 multifunction Radar
  • Mitsubishi Electric OAX-3EO/IR sensors
  • Hitachi OQQ-11 anti-mine sonar
  • NEC OQQ-25 anti-submarine sonar (VDS/TASS)
  • UUV (OZZ-5 by MHI) and USV (unknown type) for mine counter measures
  • Sea mines for offensive mine warfare

30FFM Timeline​

30FFM Artist impression. 30FFM will be fitted with 8x anti-ship missiles, a SeaRAM and an helicopter deck + hangar to accommodate an SH-60J helicopter.

MHI won a contract from the Japanese MoD in August 2018 for the production of the first two frigates and MHI is today working on the detailed design of the frigate as well as production design stage. At this time, Mitsui E&S also decided to build 30FFMs as a subcontractor to MHI.MHI won a contract from the Japanese MoD in August 2018 for the production of the first two frigates and MHI is today working on the detailed design of the frigate as well as production design stage. At this time, Mitsui E&S also decided to build 30FFMs as a subcontractor to MHI.

First steel cutting of the first 30FFM took place in September 2019 at MHI Nagasaki shipyard, and second one in October 2019 at Mitsui E&STamano shipyard. Yoshioka told Naval News in January 2020 (before the COVID-19 crisis) that the launch of the first hull was set for November this year while delivery of the first frigate to the JMSDF was set for March 2022. It is not clear if these dates have move by a couple of months (as is the case with most shipbuilding projects around the world) because of the pandemic.

In addition, this ship design is the first major surface combatant that Japan (via MHI) is actively promoting for export. OPV and Destroyer variants based on 30FFM were unveiled during PACIFIC 2019 last year in Australia.



Anmdt

Experienced member
Naval Specialist
Professional
Messages
5,227
Solutions
2
Reactions
100 23,361
Nation of residence
Turkey
Nation of origin
Turkey

30FFM: Japan’s Next Generation Frigate Taking Shape At Two Shipyards​

Two Future Multi-Mission Frigates (FFM or 30FFM) are starting to take shape at two shipyards in Japan. Images and videos obtained by Naval News from local shipspotters show the integrated mast has been fitted. Both hulls should be ready for launch before the end of the year. Xavier Vavasseur and Yoshihiro Inaba report.​

Xavier Vavasseur 21 Sep 2020

Yoshihiro Inaba contributed to this story

30FFM (also known as FFM and previously known as 30DX) is the next generation multi-mission frigate designed for the Japan Maritime Self-Defense Force (JMSDF). A total number of 22 Frigates are expected to be procured for the JMSDF.

The two shipyards in charge of building the first two frigates of the class are Mitsubishi Heavy Industries (MHI) in Nagasaki and Mitsui E&S in Okayama.

The first 30FFM frigate at MHI berth #2 in Nagasaki:
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-3-1024x768.jpg
    15 August 2020
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-4-1024x768.jpg
    22 August 2020
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-2-1024x768.jpg
    14 August 2020
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-5-1024x768.jpg
    29 August 2020
  • 30FFM-Japan%E2%80%99s-Next-Generation-Frigate-Taking-Shape-6-1024x768.jpg
    29 Augsut 2020

The second 30FFM frigate at an advanced stage of construction at Mitsui E&S in Okayama:


The-second-30FFM-frigate-at-an-advanced-stage-of-construction-at-Mitsui-ES-in-Okayama-1024x683.jpg
Picture taken 22 August 2020 by @R1000_PILOT

While in early August, the hulls were still missing their integrated mast at both locations, recent pictures showed the mast and hangar in place on the hull at Mitsui E&S in mid-August. The mast on the hull at MHI was installed the last week of August.

30FFM characteristics​



According to MHI, the 30FFM multi-mission frigate will have a full load displacement of about 5,500 tons, with a length of 132.5 meters and a beam of 16.3 meters. It will have a maximum speed in excess of 30 knots. The crew complement will be quite low, at about 90 sailors, indicating a high level of automation on board.

Atsui Yoshioka, Senior Project Manager of the Next Generation Surface Ship Project at MHI previously told Naval News at Sea Air Space 2019 that the main requirements that drove the design of this future ship are:
  • Very low radar cross section
  • Very high speed
  • Reduced crew
  • Ability to launch and recover unmanned systems

To achieve such as high speed (over 30 knots), the frigate will be fitted with a CODAG propulsion system consisting in a single Rolls Royce MT-30 gaz turbine and two MAN 12V28/33D diesel engines. Early designs of the frigate showed a combination of waterjet and propellers but the newer scale model (unveiled at SAS 2018 and showcased at various trade shows ever since) doesn’t show the underside of the hull anymore.

30FFM Advanced Integrated CIC​

30FFM CIC
The CIC features the giant 360° wall and 14 + 4 multi function consoles + 2 large tactile tables.

As we reported during SAS 2019, the 30FFM will feature a very advanced and futuristic 360° video wall in its Combat Information Center (CIC). Named the “Advanced Integrated CIC” by MHI, the CIC of the 30FFM features a circular arrangement (while every other CICs are either in square or rectangle shape) and comprises:
  • An outer rim, with 14 multi function consoles (plus two extra seats), all facing the wall
  • 3 rows at the center of the circle arrangement consisting in:
  • (what looks like) a central helm station
  • 4 more multi-function consoles (likely for the commanding officer and his XO)
  • 2 large horizontal tactical table likely for cooperative mission planning and navigation purpose

According to MHI, the 360° giant screen fulfills many roles. It can be used to display the direct surroundings of the frigate, fusing the feed and data from the many electro optical, infra red, video and even radar sensors onboard. The augmented reality technology will greatly help the crew in the field of navigation, asymmetric warfare and even in the phase of launch and recovery of unmanned surface vehicles.

In addition, the “video wall” can display any kind of information typically displayed on multi-function consoles. We were shown that the information from the engine control room, and typically displayed as part of the integrated platform management system (IPMS) can now be displayed in the CIC thanks to the video wall. Tasks such as engine control, damage control, fire fighting control can now take place from inside the CIC.

30FFM Missions​

JMSDF-Future-Frigate-to-Feature-Futuristic-360%C2%B0-Augmented-Reality-Wall-10-1024x768.jpg
Artist impression: 30FFM evading the radar from a J-20 Mighty Dragon stealth fighter thanks to its reduced radar cross section features.

The 30 FFM will increase the current number of vessels in the JMSDF as well as replace older vessels that have been responsible for coastal defense and minesweeping. So it is designed for a very wide range of missions.

Patrol around Japan​

The main mission of the 30 FFM in peacetime will be to patrol the waters around Japan. Currently, this is a mission of older destroyer (Abukuma, Hatsuyuki and Asagiri class), but the 30FFM will take over this mission by replacing these vessels.

Island Defense​

As explained later, the 30FFM is equipped with Mk.45 mod.4 5-inch gun and is also given a minesweeping/mine-laying capability. Therefore, it can be inferred that the 30FFM is also useful for island defense.
The Mk.45 is ideal for attacking enemies that have landed on the island. Also, in order to land friendly troops, it is necessary to sweep the mines laid by the enemy.In addition, laying mines to deter enemy landings is also useful.

Overseas deployment​

Currently, JMSDF continues to send destroyers to work with countries around the world to deter piracy off the coast of Somalia, Africa. However, this activity has become a huge burden for JMSDF, especially because of the North Korean situation and the increased duties of the JMSDF in the wake of China’s maritime expansion. Therefore, it is intended to send the 30 FFM to these international contributions overseas and to dedicate the destroyer to missions against China and North Korea.

30FFM weapons, sensors and unmanned systems​

JMSDF-Future-Frigate-to-Feature-Futuristic-360%C2%B0-Augmented-Reality-Wall-12-1024x768.jpg
Sensor systems aboard the 30FFM

The 30FFM will be equipped with a wide variety of weapons and systems as listed below.
  • BAE Systems Mk.45 mod.4 5-inch naval gun system ×1
  • Japan Steel Works 12.7mm Remote Weapon System ×2
  • Mk.41 VLS (fitted for but not with)
  • Raytheon SeaRAM ×1
  • MHI Type 17 anti-ship missiles ×8
  • Mitsubishi Electric OPY-2 multifunction Radar
  • Mitsubishi Electric OAX-3EO/IR sensors
  • Hitachi OQQ-11 anti-mine sonar
  • NEC OQQ-25 anti-submarine sonar (VDS/TASS)
  • UUV (OZZ-5 by MHI) and USV (unknown type) for mine counter measures
  • Sea mines for offensive mine warfare

30FFM Timeline​

30FFM Artist impression. 30FFM will be fitted with 8x anti-ship missiles, a SeaRAM and an helicopter deck + hangar to accommodate an SH-60J helicopter.

MHI won a contract from the Japanese MoD in August 2018 for the production of the first two frigates and MHI is today working on the detailed design of the frigate as well as production design stage. At this time, Mitsui E&S also decided to build 30FFMs as a subcontractor to MHI.MHI won a contract from the Japanese MoD in August 2018 for the production of the first two frigates and MHI is today working on the detailed design of the frigate as well as production design stage. At this time, Mitsui E&S also decided to build 30FFMs as a subcontractor to MHI.

First steel cutting of the first 30FFM took place in September 2019 at MHI Nagasaki shipyard, and second one in October 2019 at Mitsui E&STamano shipyard. Yoshioka told Naval News in January 2020 (before the COVID-19 crisis) that the launch of the first hull was set for November this year while delivery of the first frigate to the JMSDF was set for March 2022. It is not clear if these dates have move by a couple of months (as is the case with most shipbuilding projects around the world) because of the pandemic.

In addition, this ship design is the first major surface combatant that Japan (via MHI) is actively promoting for export. OPV and Destroyer variants based on 30FFM were unveiled during PACIFIC 2019 last year in Australia.

Sonar placement is a bit strange too, it is better to keep it far from engines but they probably make sure of the vibration isolation thus can locate it near to mid-ship. Much more comfy in wavy seas.

Last edited:

Gary

Experienced member
Messages
8,201
Reactions
21 12,732
Nation of residence
Indonesia
Nation of origin
Indonesia
yup, I don't see any MK-41 cells. Wonder why Japan decide to go FFBNW, they don't usually like this.

E2E_-wSVgA4n6eR


Saithan

Experienced member
Denmark Correspondent
Messages
8,292
Reactions
24 19,055
Nation of residence
Denmark
Nation of origin
Turkey
yup, I don't see any MK-41 cells. Wonder why Japan decide to go FFBNW, they don't usually like this.

E2E_-wSVgA4n6eR
If they can build 3-4 frigates simultaniously then I wouldn’t worry about them fitting it in no time. I assume Japan is either working on something or just going to cut cost since the frigates are going to be patroling the islands.

Also the more you arm your vessels that gives cause for countermeasures at your neighbors.

E.g how Greece overspends on defence trying to match Turkey. Imo


Gary

Experienced member
Messages
8,201
Reactions
21 12,732
Nation of residence
Indonesia
Nation of origin
Indonesia
If they can build 3-4 frigates simultaniously then I wouldn’t worry about them fitting it in no time. I assume Japan is either working on something or just going to cut cost since the frigates are going to be patroling the islands.

Also the more you arm your vessels that gives cause for countermeasures at your neighbors.

E.g how Greece overspends on defence trying to match Turkey. Imo
I hope so, or it could be that the first 8 batch going t be ASW+ASuW oriented ships while later models could be an AAW variant.

22 are planned , to replace 8 Asagiri and 6 Abukuma class.



Gary

Experienced member
Messages
8,201
Reactions
21 12,732
Nation of residence
Indonesia
Nation of origin
Indonesia
meanwhile FFM-2 (the first to be launched) in Mitsui shipyard.

E6AZsytVgAEyVFV
E6AZsytVcAMH9LH
E6AZsysVgAI57Nc


Gary

Experienced member
Messages
8,201
Reactions
21 12,732
Nation of residence
Indonesia
Nation of origin
Indonesia
FFM-1, FFM-3 and FFM-4 during various phase of construction. Images are very recent.

E5-YX5FVcAA6G-9
E5-YYEmVoAAGnks
E5-YYTKVUAIDFYU
E5-YYe8VUAI30sp


Gary

Experienced member
Messages
8,201
Reactions
21 12,732
Nation of residence
Indonesia
Nation of origin
Indonesia
requesting @MisterLike to merge this thread into one. So we have a single thread abt Mogami class FFG construction



Follow us on social media

Top Bottom
