Drop your ideas here; conceptual land units, anything crawling on land, or under-earth fits in here.


Reviewbrah

Contributor
Messages
536
Reactions
2,351
Nation of residence
Turkey
Nation of origin
Turkey

2x-4x-8x Sungur (MANPADs) added to Korkut Radar/Targeting Vehicle


Korkut turret on a Otokar Arma 8x8 for mobile air defense


Reviewbrah

Contributor
Messages
536
Reactions
2,351
Nation of residence
Turkey
Nation of origin
Turkey
M113F4 program.jpg
IRIS-T on a M113. Much simpler mechanism than Hisar A, maybe similar concept can be done with Göktuğ munitions.


Attachments

  • luftvern_834.jpg
    100.9 KB · Views: 176
  • Norwegian-Army-buying-new-mobile-air-defense-system-640x404.jpg
    23.5 KB · Views: 143
Last edited:

Reviewbrah

Contributor
Messages
536
Reactions
2,351
Nation of residence
Turkey
Nation of origin
Turkey

Our current utility vehicles don't fit todays needs




Something like KIA KLTV multi purpose utility vehicle would be a very big upgrade


Anmdt

Experienced member
Naval Specialist
Professional
Messages
5,076
Solutions
2
Reactions
94 22,541
Nation of residence
Turkey
Nation of origin
Turkey
Amphibious -Autonomous (not in terms of unmanned) coastal anti-ship system.
Couldn't do sketches yet, it will be amphibious, able to carry 4 anti ship missiles, a decent LPI or surface search radar (with AIS receiver & IFF and such), a telescopic antenna to raise-lower radar, ability to deploy and launch missiles at the sea or land. Missiles particularly will be Short to Medium range. (20-120 km)


500

Contributor
Moderator
Think Tank Analyst
Israel Moderator
Messages
752
Solutions
1
Reactions
11 2,875
Nation of residence
Israel
Nation of origin
Israel
Here is my concept of urban/asymmetric warfare tank:



* 3 crew capsule protected from all sides with thick armor (not just front like in Russian Armata).
* Armament in manless turret: 35-40-mm cannon with programmed explosion rounds (I chose this caliber for high elevation and no detonation hazard) + coaxial machine gun and ATGMs.
* Overall vehicle is quite short and relatively light (45 t). It allows good mobility in built up area.
* Compact engine at one side similar to Achzarit:



* This allows crew evacuation from rear, in that corridor u can transport injured soldiers, crew can rest there without going outside of the vehicle, transport some supplies inside...
* Electric transmission + batteries. This allows vehicle evacuation in case of engine damage + short range silent movement.


Anmdt

Experienced member
Naval Specialist
Professional
Messages
5,076
Solutions
2
Reactions
94 22,541
Nation of residence
Turkey
Nation of origin
Turkey

Mastered paint in no time :)
A dual-draft Multi-purpose amphibious vehicle. Not a vehicle which can float, it is a boat which has tires and can move on land,temporarily -settled.
Blue: Telescopic- variable height radar antenna, carries IFF and other needed sensors (EO)
Red: Stacked Anti-Ship Missiles, on a rotating hydraulic platform. (Medium-short range)
Gray: Additional buoyancy modules for lower draft-higher speed creating propeller-tunnel, unfolded in higher sea states or when antenna deployed at sea to enhance stability -sea keeping.
Orange: Operator's room
Yellow: Driver's room.
Dual-mode engine, cooled with sea-water in lower-draft mode achieving higher speeds.
Solar-powered with generator and battery packs, when settled on land can quickly unfold solar panels (with aid of driver or his assistant) from the rear-storage. battery packs enough to power radar over-night generator will be used when needed.
Autonomous, operator-engineer is high rank thus authorized to fire missiles at will.
