ctech's securearx secure satellite communication systems
- Strong protection against jamming and interception
- Low probability of interception
- Advanced Quality of Service (QoS) supported by IP networking
- One modem for fixed, land mobile, naval and airborne applications
- SOTM with ESM and EMCON features
- MIL-STD-810G and MIL-STD-461E compliant
SPECIFICATIONS
COMMUNICATION SYSTEMS
- SecureARXSingle Channel Modem
- Data 10/100/1000 Base-T Ethernet
- Protected communications for IP sub-networks
- Compatible with the STANAG 4606 Ed. 3 Waveform
- Star or mesh connected network topologies
- Applicable to operations over SHF (C, X, Ku & Ka) Bands
- 2 form factor: Single Channel 1U
SYSTEM SPECIFICATIONS
- TRANSEC protection enabled by using Orthogonal Frequency Hopping Multiple Access (OFHMA)
- NETSEC (Signaling Security)
- Optional COMSEC (AES) SECURITY
- Advanced ACM technology
- Dynamic Rate Adaptation
- Demand Assigned Multiple Access / DAMA
- Uplink Power Control BANDWIDTH OPTIMIZATION
- PC Based GUI for local Control and Monitoring
CONTROL AND MONITORING
- SNMP interface with the customer HQ
- High stability internal frequency reference
FREQUENCY REFERENCE
- Input for optional external frequency reference
RF SPECIFICATIONS
- L-Band: 950 to 1,450 MHz
- OFHMA over 500 MHz bandwidth
- Output Level: -25 to 0 dBm
- Output Level: -70 to -13 dBm
- FEC : Reed Solomon / Turbo Code
- MODCOD: BPSK 1/3, 1/6; QPSK 1/2, 1/3, 1/4, 2/3, 3/5; 8PSK 1/2, 1/3 and more
- Data Rates (bps): 20k, 25k, 32k, 40k, 50k, 64k, 128k, 256k, 384k, 512k, 768k, 1M, 1.2M, 1.6M, 2M, 3M, 4M, 8M, 16M, 32M, 50M, 100M
MODULATION AND DATA RATES
- TRANSEC protection enabled by using Orthogonal Frequency Hopping Multiple Access (OFHMA)
- NETSEC (Signaling Security)
- Optional COMSEC (AES)
SATCOM ON THE MOVE (SOTM) CAPABILITY
Military forces and government rely on robust, secure and jamming resistant communications capabilities with a low probability of Interception in friendly and hostile environments.
Similar communication capabilities are needed for government operations during emergencies, natural disasters and hazardous conditions.
CTech’s SecureARX Modem is intended for military and government applications, and can satisfy all the requirements for fixed, land-mobile, naval and airborne SATCOM use cases and scenarios.
It is the most spectrum efficient and secure high speed SATCOM modem solution available in the market, today.
By using a mix of fixed, transportable and on-the-move terminals at the same time, reliable, flexible, survivable and secure networks can easily be established, managed and operated under extreme circumstances.
CTech’s SecureARX Modem is a world class SATCOM modem solution available for military, government and official applications.
It is compatible with NATO standards, however national waveforms can easily be implemented on the same flexible design platform.
Maintenance and upgrades can easily be performed by SW/FW changes.
CTech’s proprietary management system provides users with flexible planning, control and monitoring tools while sustaining end-to-end secure and reliable communication links and networks.
Turkish company changed NATO's unchanging preference: • CTech won the tender for the protection of NATO's military satellite communications infrastructure against a manufacturer that had been doing this job as a sole source for years • CTech General Manager Cüneyd Fırat: • CTech has taken a seat in NATO's eyes on a very important product that a very large competitor has been sitting in for years. • We are talking about a job worth tens of millions of dollars. Hundreds of products will be delivered. These will be installed at various NATO stations. The job has a duration of approximately 3 years.
From inland seas to open seas and oceans: • The R&D work that started in 2006 for the need for secure satellite communication resistant to electronic jamming turned into a product, entered the inventory, and achieved export success. • CTech's SecureARX Secure Satellite Communication Systems joins the Turkish defense industry products exported to NATO • CTech General Manager Cüneyd Fırat: • Our country has many products and technologies that it can offer to NATO and the world. • CTech satellite systems are actively used in 4 countries, new countries will join. There are very important opportunities • NATO is a very important reference all over the world. • This success will create a multiplier effect in terms of technology and trade.
